Painted and waxed 900-1250mpa high strength steel strapping

Our factroy is professional and original producer and exporter in high tensile steel strapping over 10 year,which is leading manufacturer in china,that can supply 3000ton per month and delivery time is very faster . our  high tensile steel strapping ,which are manufactured from special cold rolled steel and are fully heat-treated to get high tensile strength above 930Mpa and elongation over6%.the strapping have the great advantage of excellent physical properties,maximum safety,shock resistance,etc.and that are produced to meet various heavy duty applications,such as steel industy(steel coil,steel sheet,steel tube,steel bar) plywood packing,timber packing,brick packing,cotton,wool,jute,glass,oil tank,other heavy duty products.etc
Physical Properties
Grade

 Tensile strength Mpa       min

Enlongation%                                     Min
930KD 930 10
980KD 980 12
1150KD 1150 8
1250KD 1250 6

Size
Thickness(mm)  width(mm)
0.4 16mm
0.5 16,19
0.6 16,19
0.7 19
0.8 19,25.4,31.75,62
0.9 19,25.4,31.75,32,40
1.0 19,25.4,31.75,32,40
1.2 31.75,32,40

Thickness tolerance

0.4-0.6mm +/- 0.02mm

0.7-1.2mm  +/- 0.03mm

width tolerance:

16mm-40mm - 0.10mm


Finish
Blue tempered + Waxed
Painted + Waxed, such as black, brown, green, etc
Zinc coated + waxed

Coil Dimension
Coil I.D: 200mm, 300mm, 406mm
Coil O.D (max): 1000mm

Coil winding    Coil face  Coil weight
Ribbon wound

16mm,19mm,

25.4mm,31.75mm,

32mm,40mm

45-50kgs
Oscillated wound 63.5mm 50kgs
Jumbo wound 190mm 200-400kgs
